Purpose-built for 28KG heavy-duty barrel water, its custom integrated gripper simultaneously handles barrel packs and slip sheets, delivering high-rigidity stability and fully automated unmanned palletizing at 210 packs per hour.

Integrated Gripping, Precise & Efficient
Heavy-Duty Structure, Rock-Solid Stability
Cycle-Matched Speed, Stable Palletizing
Cost Reduction & Efficiency, 24/7 Production
Compact & Flexible, Strong Adaptability

SPIN’s Rotary Column Palletizer: Dual-station, continuous operation, no speed loss.

Inquiry

Description

Integrated Palletizing Machine, Dual-Station Column Palletizer for 28KG Bucket Mineral Water and Slip Sheets, Equiped with Custom Integrated Gripper, with CE certification.

Product: 28kg shrink-wrapped bottled water

Output: 210 packs/hour

Stacking Pattern: 9 packs/layer, 3 layers in total.

SPIN’s Column rotating palletizer: Dual-station, continuous operation, no speed loss.

> To see the palletizer in action, click here to watch our YouTube video.

Core Features of Integrated Palletizing Machine

1. Custom integrated gripper simultaneously handles “28KG water barrels + slip sheets,” enabling multi-functionality without extra suction equipment.

2. High-rigidity column structure designed specifically for 28KG heavy loads. Ensures smooth, vibration-free operation, eliminating injuries and damage risks from manual handling.

3. Perfectly matches 210 packs/hour capacity. Utilizes a 3×3 grid layout with three-layer stacking for a stable center of gravity, ensuring no collapse during forklift transport.

4. Fully automated production line drastically reduces labor costs and product friction loss, seamlessly supporting 24/7 shift operations.

5. Compact footprint with low installation requirements. The gripper module is easily changeable, offering strong cross-category versatility beyond this specific project.

Standard Parameters of Model MR-180

Power supply/Power	AC 380V±/5% three-phase four-wire
Pneumatic Requirements	Grippers/Fixtures: 0.6-0.8 MPa, ≥0.3 m³/min Suction Cups: 0.6-0.8 MPa, 0.6-1.1 m³/min Total air reservoir capacity >600 L
Dimensions	Overall height 3m, rotation coverage radius 2.5m, footprint 5×3 m²
Cable Length	3m (from robot body to control cabinet)
Palletizing Height Limit	≤1600mm (grippers/fixtures) ≤1800mm (suction cups)
Applicable Scope	10-50kg product Including: bags, cartons, sheets, blocks, or similar products
Palletizing efficiency	400-500 cycles/hour (theoretical maximum)
Power Consumption	Robot body: 6.5 kW Shaping conveyor/positioning conveyor: 1.5 kW
Pallet reference	≤1400×1600mm (including actual stack pattern)
Customizable item	Cross arm length, column height, base length, special grippers
follow-on upgrade	Vision recognition, pallet conveyor line ton bag lifting reciprocating mechanism, anti-collapse linkage system

We Spin supply three mainstream palletizing robots: cartesian coordinate XYZ robots, column-type palletizer, and articulated robotic arms. For detailed information on the three palletizing machine types, click here: Automated Palletizing Solutions: A Complete Guide to Cartesian, Column-Type, and Articulated Robots

SPIN’s Column Rotating Palletizing Robot: Dual-station, Continuous Operation, No Speed Loss.

Features of Dual-station Rotary Palletizer:

Takes up less floor space than a robotic arm, simple to fix, and flexible in layout.
Operates via a straight-arm rotation method, offering large coverage; safety fences and light curtains are required to improve safety.
Dual-station design: no efficiency or speed requirements for personnel handling full stacks or placing empty pallets. Simply remove the full stack and replace with an empty pallet on the other side before the stack is completed.
Continuous operation, alternating left/right or right/left with no actual loss of speed. After manually placing empty pallets and pre‑ordering a new stack position, the safety factor is extremely high.
Slightly higher initial investment, but significant potential for future output increase (for 25 kg bagged products with air, max speed 450 cycles/hour; for 25 kg bagged products without air, max speed 500 cycles/hour).

Typical Applications:

Suitable for medium-to-low-speed palletizing production lines with a fan-shaped working area, compact space, and high cycle time requirements. Examples include palletizing bottled water, boxed beverages, food boxes, etc.

Maintenance Guide:

Daily Maintenance FAQ for Palletizers and Depalletizers

To custom palletizing machine / depalletizing robot / bag opening machine, what we need from you:

Product Name	(Scientific name of the product)
Packaging Form	(Open-top, Valve, Boxed, Sheet, etc.)
Product Specification	(kg)
Product Dimensions	(Length) × (Width) × (Height) mm
Pallet Dimensions	(Length) × (Width) × (Height)
Stacking Dimensions	(Length) × (Width) × (Height, including pallet)
Stacking Pattern	______ pieces per layer, ______ layers in total
